    Customized RF Signal Power Amplifier Jammer Module 5.2GHz 50W

    Ask Lasest Price
    Brand Name : flysafe
    Price : Negotiable
    Delivery Time : 5-8 work days
    Payment Terms : LC,T/T,MoneyGram,Western Union,D/P,D/A,L/C
    • Product Details
    • Company Profile

    Customized RF Signal Power Amplifier Jammer Module 5.2GHz 50W

    Product Parameters

    Frequency5.2 GHz
    Work Temperature-20~+70 ℃
    Max Output Power50 W
    Work VoltageDC28 V
    Max Gain47 dB
    Flatness±1 dB
    Max Current4 A
    Output VSWR≤1.5
    Output ConnectorSMA/F 50Ω Customized
    Power Amplifier Efficiency45 when Max Output
    Switch Control0V off /0.6 on
    Standing Wave ProtectionOK
    Temperature Protection75 ℃
    Size132*53*17 mm
    Weight0.2 Kg

    Product Description

    The 5.2 G 50w Signal Power Amplifier Module is a specialized component designed to amplify radio frequency (RF) signals at the 5.2 GHz frequency. Designed to achieve optimum performance at 5.2 GHz, it provides consistent functionality and minimizes distortion. Typically, their input and output connections are set up to handle RF signals with specific impedances to ensure proper impedance matching and minimize signal reflections.
